Faster everywhere.....
That’s the legend and the legacy of SuperSix EVO. Always has been. Always will be. Its blend of efficient aerodynamics, feathery weight, and telepathic handling enabled the fourth generation EVO to win everything from World Championships, Tour leader’s jerseys, KOM Polka Dots, Paris-Roubaix, and Paris Gold, to more town-line sprints and local hero bragging rights than you can count. For this new, fifth generation of EVO, our mission was clear – keep the unmatched speed and handling while shaving weight everywhere we could.
The results are stunning. The lightest disc frame and fork we’ve ever made. Even less aerodynamic drag. All wrapped in a package that looks as fast standing still as it does crossing the finish line. We’ve even created a few SL variants for the true weight-weenies out there, with setups so light, the UCI wouldn’t approve them. All in all, the fastest bike anywhere just got faster everywhere. The legend of EVO continues.
Features
Frameset
| Frame | LAB71 SuperSix EVO, Gen 5, Ultralight Series 0 Carbon, 12x142 thru-axle, BSA 68mm threaded BB, flat mount disc, integrated seat binder, UDH |
Suspension
| Fork | LAB71 SuperSix EVO, Gen 5, Ultralight Series 0 Carbon, integrated crown race, 12x100mm thru-axle, flat mount disc, internal routing, 1-1/8" to 1-1/4" Delta steerer, 55mm offset (44-54cm), 45mm offset (56-61cm) |
Brakes
| Front Brake | SRAM RED AXS, hydraulic disc, Paceline X 160mm |
| Rear Brake | SRAM RED AXS, hydraulic disc, Paceline X 160mm |
Drivetrain
| Shift Levers | SRAM RED AXS, hydraulic disc |
| Front Derailleur | SRAM RED AXS, braze-on |
| Rear Derailleur | SRAM RED E1, 12-speed |
| Cassette | SRAM RED XG-1290, 12-speed, 10-30t |
| Chain | SRAM RED 12-speed |
| Crankset | SRAM RED AXS Power Meter, 48/35t (165mm 40-50cm, 170mm 52-56cm, 172.5mm 58-61cm) |
| Bottom Bracket | CeramicSpeed BSA DUB Coated Version |
Wheels & Tyres
| Rims | DT Swiss ARC 1100 Spline 38 CS, carbon, 20mm inner width, 38mm depth |
| Hubs | DT Swiss 180 Spline, SINC ceramic bearings, centerlock, straight pull - (F) 12x100mm, (R) 12x142mm, Ratchet EXP 36 |
| Spokes | DT Swiss Carbon Spoke |
| Tyres | Vittoria Corsa Pro, 700x28c Tube Type, TPU tube optimised |
Cockpit
| Stem | Included in Handlebar |
| Saddle | Fizik Vento Antares 00, carbon shell and rails, 140mm |
| SeatPost | Cannondale C1 Aero 40 Carbon V2, Ti Hardware, 0mm offset (4454cm), 15mm offset (56-61cm) |
Weight
| Weight | 6.35 kg |
Specifications subject to change without notice.
